GENERAL CUTTING TYPE 42
( DEPRESSED CENTER )
DSIC STANDARD
| Dia | Thickness | Hole | Max RPM | Grit/(code no.) |
|---|---|---|---|---|
| 10″ – 250 mm | 1/8″ – 3.2 mm | 1″ – 25.4/20 mm | 6100 | A30R (FS-250-10 -32 st.) |
| 12″ – 300 mm | 1/8″ – 3.2 mm | 1″ – 25.4/20 mm | 5100 | A30R (FS-300-12 -32 st.) |
| 14″ – 350 mm | 5/32″ – 3.9 mm | 1″ – 25.4/32 mm | 4400 | A30R (FS-350-14 -39 st.) |
| 16″ – 400 mm | 5/32″ – 3.9 mm | 1″ – 25.4/32 mm | 3850 | A30R (FS-400-16 -39 st.) |
| Dia | Thickness | Hole | Max RPM | Grit/(code no.) |
|---|---|---|---|---|
| 10" - 250 mm | 1/8" - 3.2 mm | 1" - 25.4/20 mm | 6100 | WA30S (FS-250-10-32pro) |
| 12" - 300 mm | 1/8" - 3.2 mm | 1" - 25.4/20 mm | 5100 | WA30S (FS-300-12-32pro) |
| 14" - 350 mm | 5/32" - 3.9 mm | 1" - 25.4/32 mm | 4400 | WA30S (FS-350-14-39pro) |
| 16" - 400 mm | 5/32" - 3.9 mm | 1" - 25.4/32 mm | 3850 | WA30S (FS-400-16-39pro) |
